Main Features:

Windows XP operation system based

4 sets of scroll menus mouse control friendly

Ultrasound Work-Station managing system

Powerful measurement & calculation software packages

Patient data managing system

THI(tissue harmonic imaging)

4X images

pseudo color

Dicom 3.0

Technical Specification :

Scanning mode :Convex/Linear/Micro-convex

Display modes :B,B+B,B+M,M,4B

Scanning depth :40mm-240mm

Gray scales :256

Cine-loop :≥500 frames

Image permanent storage :≥1000 frames

hard disk :≥80G

Image conversion :up/down, left/right, black/white

Local zoom :6 times both in real-time and frozen

pseudo color :10

Measurement :General,Gynecolorgy,ObstetricGynecolorgy,Cardiac,Urology,

                        Miniorgan,Orthopedics

Probes selectable :convex, linear, micro-convex, transvaginal and dorectal

Port:PAL-D,XGA,RS-232,USB2.0,DICOM3.0

Monitor :12 inch LCD

Body marks :40

Comment :Pid,date&time, name, sex, age, doctor, hospital,annotation,……

Wide application :abdomen, OB/GYN, urology, cardiology,……

Power supply :AC 110V~240V, 50Hz/60Hz

Probe connector :2

Options:

L40/7.5MHz Linear

20R/5.0MHz Micro-Convex

13R/6.5MHz Transvaginal?Convex

10R/6.5MHz Transvaginal?Convex

L40/7.5MHz Endorectal Linear

Video Printer

Biopsy bracket
