General information:

– Continuous and pulsed ultrasound therapy

– Multi-frequency treatment head with 1 and 3 Mhz

– User friendly, lightweight design with large blue backlight LCD display

– Head over heating and cable connection auto-detection

– Waterproof Head

– 17 Protocols with most appropriate parameters for clinical indications

– Free programmable memory positions, for record your own protocols

– Very well suited for the treatment of clinic patients or patients at home

Technical specification:

– Electronic Circuit Micro controlled

– Frequency: 1 and 3 Mhz Continuos and pulsed

– Pulse Frequency: 100Hz, 48Hz, 16Hz (± 10%)

– Duty Cycle: 10%, 20%, 50%.

– Intensity: 0-2 W/cm2 continuos / 0-3 W/cm2 pulsed

– Time switch: 1 to 20 minutes

– Mains Power: 100-230 V, (50/60Hz)

– Maximum consumption: 65 VA

– Dimensions: 31 x 11 x 21cm (WxHxD)

– Weight: 2,6 Kg

– Treatment Head: 5cm2 (Type collimated)

– Effective radiation area (ERA): 3,5 cm2 (± 10%)

– Bean nonuniformity ration (BNR) < 6.0:1

– Waterproof transductor: IPX7

– Safety Tests: IEC 60601-1, IEC60601-1-2, IEC 60601-2-5
